Flamco - Pro PDm 1.5 Digital Pressurisation Unit - Wall Mounted - 1.5 Bar

Wall-mounted, plug-and-play digital pressurisation unit with preset delivery pressures, the Pro PDm keeps sealed systems at stable minimum pressure using an electronic pressure transducer and intuitive microprocessor control.

A 4 Ltrs internal break tank and top-up capacity to 12 L/min suit commercial, industrial and larger residential installs (guide volume ≤ 50,000 Ltrs). Factory preset delivery options of 1.0, 1.5, 2.0 or 2.5 Bar speed commissioning; setpoints are also adjustable in 0.1 Bar steps.

• Self-venting pumps and presets minimise conventional commissioning
• Dry-run, anti-seize (2-second pulse after 60 days) and flood-protection routines
• System fill mode, pump pulse option and on-screen 12-month service reminder
• MODBUS RTU, password-protected menus and bi-directional programming
• Finished in grey (RAL 7016); power supply 230V 50Hz 1ph

Real-world product applications

• Boosting water pressure to multiple outlets in a building
• Maintaining stable pressure where demand varies
• Supplying water from storage tanks to distribution pipework
• Supporting general water supply and transfer systems
• Assisting with pressure control in utility installations

Key Product Features

• Applications: commercial, industrial and residential sealed systems (≤ 50,000 Ltrs)
• Hydraulics:4 Ltrs break tank; up to 12 L/min top-up
• Pressure control: factory presets 1.0/1.5/2.0/2.5 Bar; set in 0.1 Bar increments
• Protection: dry-run; anti-seize; flood protection (pump runtime limiter, excessive start alarm)
• Controls: system fill mode; pump pulse; on-screen 12-month service reminder
• Comms & access:MODBUS RTU; password protected; bi-directional menu
• Event logging: alarms; pump run counter (per pump); cumulative run-hours (per pump); electrical interruption
• Volt-free contacts (standard): Common Alarm (N/C), High Pressure (N/O), Low Pressure (N/O), Sensor Health (N/O), Pump 1 Health (N/O), Pump 2 Health (N/O)
• Optional VFCs (factory board): Low Pressure Warning (N/O), High Pressure Warning (N/O), Low Water in Break Tank (N/O), Low Additive in Holding Tank (N/O), Pump 1 Run for Top-up (N/O), Pump 2 Run for Top-up (N/O)
• Finish & power: grey powder coat (RAL 7016); 230V 50Hz 1ph

Flamco (est. 1956) is a Dutch manufacturer of HVAC and plumbing system components, including expansion vessels, air separators and pressurisation accessories. Their ranges are used in heating and chilled-water circuits and potable water systems across domestic and commercial installations.
