Grundfos - GT-U-8 Vertical Cold Water Bladder Tank - 25 Bar. - 8 Ltr

Name: Grundfos - GT-U-8 Vertical Cold Water Bladder Tank - 25 Bar. - 8 Ltr
Brand: Grundfos
SKU: 96573347
Price: 83.4 GBP
Availability: InStock

Part Number:

96573347

GT-U-8 PN25 G 3/4 V Grundfos GT-U are bladder pressure tanks with a capacity ranging from 8 to 3000 litres. The tanks are designed for a maximum operating pressure between 10, 16 and 25 bar and a maximum liquid temperature of 70 °C.

View Description | Data Sheet(s)

This item is now obsolete. Please view our alternatives below.

£218.40 RRP £83.40 £69.50

Free Standard Delivery

Add to Wishlist

Compare

Skip to the end of the images gallery

Skip to the beginning of the images gallery

Description

GT-U-8 PN25 G 3/4 V

Grundfos GT-U are bladder pressure tanks with a capacity ranging from 8 to 3000 litres. The tanks are designed for a maximum operating pressure between 10, 16 and 25 bar and a maximum liquid temperature of 70 °C. The tanks are approved for drinking water.

The tanks are steel pressure tanks, with non-toxic butyl rubber bladder enclosed by compressed nitrogen.

A pressure tank ensures controlled pressure in the water supply and thereby limits the switching frequency of the pump unit in case of low water consumption or loss due to leakage. This ensures increased comfort in your installation by limiting the start and stop frequency of your pump. It also creates a more stable assembly by compensating for pressure drops when a tap is opened, while reducing problems with water hammer in the pipes.

Key Product Features

Net weight: 2.4 kg
Approvals: CE,EAC
Temperature Liquid Range: 0 .. 70 °C
Connection Size: 3/4 inch
Type of connection: G
Maximum Operating Pressure: 25 bar

This is a Grundfos Pressure Vessel product used in professional pump and fluid handling applications.

Grundfos (est. 1945) is a Danish pump manufacturer known for high-efficiency circulators, multistage boosters, borehole and wastewater pumps, plus packaged pressure systems. The range covers HVAC circulation, domestic hot water recirculation, pressure boosting, industrial water transfer and public water management, with strong focus on energy efficiency and intelligent controls.

More Information
Price	£69.50
Manufacturer	Grundfos
Warranty	1 year guarantee
Dimensions	320mm (h) x 206mm Diameter
Bars	25 bar
Capacity	8Ltr
Pressure Rating	25 Bar
Duty Type	Domestic
Pump Type Filter	Pressure Vessel
Next Day Delivery	No
Manufacturers Part Number	96573347
