Wilo - Atmos GIGA-B 50/105-0,55/4 Centrifugal Pump - 400V - Three Phase

Single-stage glanded centrifugal pump in monobloc design for installation on a base including foot on the pump housing.

Low-oscillation and low-noise monobloc design with lanternn and rigidly connected standard motor.

With force-flushed, bidirectional bellows mechanical seal (from 37kW/4-pole, optionally available with a cartridge mechanical seal in back pull-out design for mechanical seal replacement without dismantling the motor) and cavitation-reducing impeller.

Flange with R1/8 pressure measuring connections. All grey Cast Iron components are cataphoretic-coated.

Pumps with motors ≥5.5KW are equipped as standard with a PTC thermistor sensor for motor protection.

The motor terminal box ≤ 7.5 KW can be made of metal or plastic. If a metal terminal box is absolutely necessary, please order the appropriate special variant. The motor terminal boxes > 7.5 KW are always made of metal.

Real-world product applications

• General water transfer between tanks and systems
• Supplying water for domestic or light commercial use
• Supporting irrigation and washdown duties
• Circulating or transferring water in utility applications
• Assisting with general pumping and transfer tasks

Key Product Features

• Min. fluid temperature: -20C
• Max. fluid temperature: 140C
• Min. ambient temperature: 0C
• Max. ambient temperature: 40C
• Maximum operating pressurePN: 16bar
• Note on dimensioning: 16 bar. to 120 C, 13 bar. to 140 C
• Minimum efficiency index (MEI): ≥0,4
• Mechanical seal for pumping water up to = +140C. Up to T ≤+40C, a glycol admixture of 20% to 40% by volume is permissible. An alternative mechanical seal must be provided for water-glycol mixtures with a glycol content of >40% to max. 50% by volume and a fluid temperature of >+40C to max. +120C or other fluids that differ from water. When using water-glycol mixtures, the use of an S1 variant with a corresponding mechanical seal is generally recommended
