Calpeda - MXH 1605/A Horizontal Multistage Pump - 400V - Three Phase

Name: Calpeda - MXH 1605/A Horizontal Multistage Pump - 400V - Three Phase
Brand: Calpeda
SKU: 62253051000
Price: 1644.7 GBP
Availability: InStock

Part Number:

62253051000

The Calpeda MXH 1605/A Horizontal Multistage Pump - 400v - Three Phase is a Multistage pump. Voltage for this item is 400V.

View Description | Data Sheet(s)

This item is now obsolete. Please view our alternatives below.

£2,192.93 RRP £1,644.70 £1,370.58

Free Standard Delivery

Add to Wishlist

Compare

Skip to the end of the images gallery

Skip to the beginning of the images gallery

Description

The Calpeda MXH 1605/A Horizontal Multistage Pump - 400v - Three Phase is a Multistage pump. Voltage for this item is 400V. This is a Surface Mounted pump which can be suitable when the pump can sit in a dry, accessible location and draw liquid in via a suction pipe or hose.

Calpeda MXH is a range of horizontal multi-stage close-coupled pumps in chrome-nickel Stainless Steel, designed for compact installations and efficient pressure boosting. The range features a robust, single-piece construction (including a barrel casing), with front suction and radial delivery at the top.

Range options

MXH: Stainless Steel construction (AISI 304)
MXHL: Stainless Steel AISI 316L versions for selected sizes
MXH EI: versions available with integrated I-MAT inverter for compact variable-speed pressure control (range dependent)

Typical applications

Water supply and pressure boosting
Hot and cold water distribution (application dependent)

Calpeda's MXH series are horizontal Multi-Stage close coupled pumps in chrome-nickel Stainless Steel.

They have a compact and robust construction, without protruding flange and with single-piece lanternn bracket and base.

They come complete with a single-piece barrel casing, with front suction port above pumps axis and radial delivery at top.

The filling and draining plugs are on the middle of the pump, accessible from any side (like the terminal box).

Real-world product applications

Pressure boosting for water supply systems
Feeding distribution networks requiring higher pressure
Supporting irrigation and washdown water delivery
General clean-water transfer for utility systems
Supplying water to buildings and equipment

Key Product Features

For water supply
For clean liquids, without abrasives, which are non-aggressive for Stainless Steel (with appropriate seal materials, on request)
Universal pump, for civil and industrial applications, for
Water type: Clean or Discoloured
Voltage: 400V

Calpeda pumps cover a wide mix of water-moving applications, from everyday clean-water transfer through to drainage, wastewater handling, swimming pool water circulation and packaged system solutions. They are an long-standing Italian manufacturer of pumping systems, established in 1959, with product ranges used across domestic, commercial and industrial applications.

More Information
Price	£1,370.58
Manufacturer	Calpeda
Warranty	1 year guarantee
Electrical supply	400V
AC Power	Three Phase
Water type	Clean or Discoloured
Pump Type Filter	Multistage
Duty Type	Commercial
Submersible vs Surface Mounted	Surface Mounted
Inlet Connection	2"
Outlet Connection	1 1/2"
Next Day Delivery	No
Manufacturers Part Number	62253051000
