Jabsco - Maxi Puppy Self-Priming Pump - 24V - 45 Ltr/min

Name: Jabsco - Maxi Puppy Self-Priming Pump - 24V - 45 Ltr/min
Brand: Jabsco
SKU: 23610-3103
Price: 334.8 GBP
Availability: InStock

Part Number:

23610-3103

Jabsco Maxi Puppy is a higher-capacity flexible-impeller pump in the Puppy Series, commonly referenced for continuously rated bilge pumping and high-flow washdown duties (model dependent).

View Description | Data Sheet(s)

This item is now obsolete. Please view our alternatives below.

£434.12 RRP £334.80 £279.00

In stock

Free Standard Delivery

Add to Wishlist

Compare

Skip to the end of the images gallery

Skip to the beginning of the images gallery

Description

Jabsco Maxi Puppy is a higher-capacity flexible-impeller pump in the Puppy Series, commonly referenced for continuously rated bilge pumping and high-flow washdown duties (model dependent).

Typical applications

High-capacity bilge pumping (duty dependent)
Deckwash and washdown systems (system dependent)
General-purpose marine transfer where higher flow is required

The Jabsco Maxi Puppy Self-Priming Pump - 24v is a Self Priming Pump item. Voltage for this item is 24V. It has an actual flow rate of 45 Ltr/min. This is a Surface Mounted pump which can be suitable when the pump can sit in a dry, accessible location and draw liquid in via a suction pipe or hose.

The operating pressure of this is 1 bar.

Real-world product applications

Drawing water from shallow sources such as tanks and sumps
General water transfer where suction lift may be required
Supporting site drainage and utility pumping duties
Supplying water for irrigation and washdown systems
Feeding water to distribution pipework

Key Product Features

Connections: - for 25mm (1") bore hose or 1/2" BSP
Dimensions: - 220mm long, 120mm wide, 85mm high
Fuse Size: - 15(amp)
Output: - up to 45 litres/minute (10 gallons/minute)
High capacity, continuously rated bilge pump
Self priming up to 2.4m vertical lift
Simple, fully serviceable design with few wearing parts
Can generate pressures up to 1 bar. (15 psi)
Bronze body, Stainless Steel shaft
Packaged Dimensions: L:28.00 x H:13.00 x W:15.00cm
Flow rate: 45 Ltr/min
Water type: Clean or Discoloured
Voltage: 24V

Jabsco (est. 1938) manufactures pumps for marine and industrial fluid handling. Their ranges include diaphragm pumps, flexible impeller pumps and washdown/bilge solutions. Typical applications cover freshwater pressure, bilge pumping, fuel or liquid transfer and general marine service duties.

More Information
Price	£279.00
Manufacturer	Jabsco
Warranty	1 year guarantee
Dimensions	L220mm x W120mm x H85mm
Bars	1 bar
Electrical supply	24V
AC Power	Single Phase
Flow Rate	45 Ltr/min
Water type	Clean or Discoloured
Switch	None
Duty Type	Commercial
Submersible vs Surface Mounted	Surface Mounted
Pump Type Filter	Self-Priming
Next Day Delivery	Yes
Manufacturers Part Number	23610-3103
