DAB - ESYTANK 300 + ESYBOX - 230V

ESYBOX is a patented booster system, unique in its category, with high performance, efficient, compact, easy and satisfying in the use both for the installer and the final user.
When ESYBOX mini is the solution for water boosting in small dwellings, ESYBOX offers the same advantages in collective residential applications, such as villas or condos. Wireless technology enables to set up booster sets up to 4 pumps.

ESYTANK/ESYTANK 300 Mini is a tank with a 275l capacity, suitable for use with drinking water.

It features a valve for filling from the mains with an unrestricted air gap float for backflow prevention, in line with standard UNI EN 1717.

The CAT3 version features an AG-type air gap overflow system with DN50 outlet, while the CAT5 has an AB-type air gap system with auxiliary DN50 outlet.

The AG- or AB-type overflow systems on both versions are located at the back; The water tank comes with an insect guard that can be attached with special screws.

ESYTANK/ESYTANK 300 Mini comes with ESYDOCK, suction pipe with foot valve and delivery line.

Operating range: capacity up to 120 l/min; head up to 65 m.

Liquid temperature range: from 0°C to +35°C for domestic use for other use: from 0°C to +40°C.

Insulation: Horizontal or vertical fixed position.

Maximum operating pressure: 8 Bar. (800 kPa)

The DAB ESYTANK 300 + ESYBOX is a Booster Set item. Voltage for this item is 230V.

The operating pressure of this is 6 Bar.

Key Product Features and Use

• Pumped fluid: clean, free from solids or abrasive substances, not viscous, not aggressive, not crystallised and chemically neutral
• Maximum liquid temperature: 40°C
• Maximum environment temperature: 50°C
• Maximum capacity: 275 litres
• Supply pressure allowed at mains water inlet: max. 6 Bar.
• Dimensions of mains water inlet pipe: ¾"
• Dimensions of delivery pipe: 1"
• Dimensions of overflow pipe connection: DN 50
• Dimensions of front discharge (not drilled): DN40
• Water type: Clean or Discoloured
• Voltage: 230V

Real-world product applications

• Boosting water pressure to multiple outlets in a building
• Maintaining stable pressure where demand varies
• Supplying water from storage tanks to distribution pipework
• Supporting general water supply and transfer systems
• Assisting with pressure control in utility installations
