Wilo - Star-Z 20/7-3 Drinking Water Circulator Pump - 230V - Single Phase - 150mm

Name: Wilo - Star-Z 20/7-3 Drinking Water Circulator Pump - 230V - Single Phase - 150mm
Brand: Wilo
SKU: 4081203
Price: 497.28 GBP
Availability: InStock

Part Number:

4081203

This circulator is suitable only for drinking water. Domestic Hot water circulator, glandless pump with manual three-stage variable speed control for pipe installation.

View Description | Data Sheet(s)

This item is now obsolete. Please view our alternatives below.

£621.60 RRP £497.28 £414.40

Free Standard Delivery

Add to Wishlist

Compare

Skip to the end of the images gallery

Skip to the beginning of the images gallery

Description

This circulator is suitable only for drinking water.

Domestic Hot water circulator, glandless pump with manual three-stage variable speed control for pipe installation.

Blocking-current proof motor. Pump housing made of bronze, impeller made of fibreglass-reinforced plastic, ceramic shaft with resin-impregnated carbon friction bearings.

Real-world product applications

Circulating water around closed-loop pipework systems
Maintaining flow through distribution circuits
Supporting recirculation in building services installations
Keeping consistent flow through equipment or pipe runs
Assisting with loop circulation for system efficiency

Key Product Features

Max. fluid temperature: 65 °C
Min. fluid temperature: 2 °C
Min. ambient temperature: 0 °C
Max. ambient temperature: 40 °C
Temperature range at max. ambient temperature +40 °CT: +2...+65
Maximum operating pressurePN: 10 bar
Max. permitted total water hardness: 3.21 mmol/l (18°dH)

Wilo (est. 1872) is a German manufacturer delivering building-services and water-management pumps. Their ranges include circulators, booster sets, drainage pumps and sewage systems. Wilo products are commonly used in heating and cooling circulation, pressure boosting, commercial building services and public water infrastructure.

More Information
Price	£414.40
Manufacturer	Wilo
Warranty	1 year guarantee
Electrical supply	230V
AC Power	Single Phase
Water type	Clean or Discoloured
Pump Type Filter	Circulator Pump
Duty Type	Domestic
Submersible vs Surface Mounted	Surface Mounted
Next Day Delivery	No
Port To Port	150mm
Connection Type	G 1¼
Manufacturers Part Number	4081203
