Tsurumi - GAM100 Centrifugal Pump - 230V - Single Phase

The Tsurumi - GAM100 Centrifugal Pump - 19-15-1071 - 230V - Single Phase (SKU 19-15-1071) is a versatile and efficient pumping solution for various industrial and agricultural Uses. This non-self-priming, single-stage centrifugal pump is equipped with an open impeller, making it suitable for handling slightly dirty, non-aggressive liquids.

GA(M)100is a non self-priming, single-stage, centrifugal pump. With an open impeller, it can pump non-aggressive liquids, which are slightly dirty and is designed for irrigation and general circulation, in industrial Uses. Optional pump control and energy management systems are available.

dynamic performance:

• Maximum flow rate: 260 l/min
• Maximum head: 17 metres

Motor:

• Power output: 0.75 kW
• Voltage: 230V (single-phase)

Connections:

• Inlet: 1½" BSPF
• Outlet: 1½" BSPF

Sizing and Weight Information:

• Width: 182 mm
• Length: 311 mm
• Height: 232 mm
• Dry weight: 15 kg

The GAM100 is designed for continuous duty and can operate in ambient temperatures of up to 40°C. It has a maximum suction lift of 8 metres when equipped with a foot valve.

Suitable fluids:

• Clean water
• Slightly dirty water
• Temperature range: 0 - 90°C

Uses:

• Industry
• Agriculture
• Horticulture
• Transfer
• Circulation

The pump features durable components to ensure reliable dynamic performance:

• Cast Iron pump body
• Brass impeller
• AISI 304 Stainless Steel motor shaft
• Ceramic/Graphite/NBR mechanical seals

With its robust construction and versatile capabilities, the Tsurumi - GAM100 Centrifugal Pump is an excellent choice for various pumping needs in industrial and agricultural settings.

Real-world product applications

• General water transfer between tanks and systems
• Supplying water for domestic or light commercial use
• Supporting irrigation and washdown duties
• Circulating or transferring water in utility applications
• Assisting with general pumping and transfer tasks

Key Product Features

• Flow rate: 260 Ltr/min
• Water type: Clean or Discoloured
• Voltage: 230V
• Maximum head: 17m

Tsurumi (est. 1924) is a Japanese manufacturer specialising in heavy-duty submersible pumps for drainage, construction dewatering and wastewater. Product ranges include contractor dewatering, slurry and sewage pumps. Common applications include site dewatering, civil engineering, tunnelling, quarrying and public wastewater projects requiring solids handling.
