Tsurumi - KPM80 Centrifugal Pump - 230V - Single Phase

The Tsurumi - KPM80 Centrifugal Pump - 19-15-1080 (SKU 19-15-1080) is a robust and efficient peripheral pump designed for industrial and domestic Uses requiring high pressure with relatively low power consumption. This single-phase, 230V model is part of Tsurumi's KP(M) series of industrial peripheral pumps, renowned for their steady operating curves and reliability.

TheKP(M)pumps are non self-priming, peripheral centrifugal pumps with Cast Iron pump bodies. Capable of high heads and pressures in domestic and industrial Uses.

Optional pressure controller will provide dry-run protection and automatic operation. (sold separately)

Performance

• Flow rate: 50 litres per minute
• Maximum head: 55 metres
• Power: 0.60 kW

Sizing and Weight Information

• Inlet/Outlet: 1" (BSPF)
• Width: 135 mm
• Length: 295 mm
• Height: 161 mm
• Dry weight: 9.5 kg

Electrical

• Frequency: 50 Hz (assumed based on standard European specifications)

The KPM80 is suitable for various Uses, including:

• Increasing system pressure in aqueducts
• Automatic water distribution in small autoclave tanks
• Domestic water pressure boosting
• Industrial processes requiring consistent high-pressure

• Liquid temperature: Up to 60°C
• Ambient temperature: Up to 40°C
• Total suction lift: Up to 7 metres
• Duty cycle: Continuous

The pump is built with durability in mind, featuring:

• Cast Iron pump body
• Brass impeller
• Stainless Steel shaft
• Ceramic/graphite mechanical seal

This construction ensures the pump can handle clean water and non-aggressive liquids without sand or other solid impurities.

Real-world product applications

• General water transfer between tanks and systems
• Supplying water for domestic or light commercial use
• Supporting irrigation and washdown duties
• Circulating or transferring water in utility applications
• Assisting with general pumping and transfer tasks

Key Product Features

• Flow rate: 50 Ltr/min
• Water type: Clean or Discoloured
• Voltage: 230V
• Maximum head: 55m
